Harbin Shenneng Motor Co., Ltd.

+
  • o7.jpg

Deep sea 11000 m 32kg thruster

Model: UWT-32 Output power: 600W Rated voltage: 110VDC ± 5% Rated speed: 850 r/min Rated thrust: ≥ 32kg (forward and reverse) Motor material: optional stainless steel, aluminum alloy, titanium alloy Propeller material: optional aluminum alloy, titanium alloy Control power supply: 24VDC Control mode: analog control, CAN Speed feedback: pulse feedback, CAN drives: external Compensation mode: self-compensation Working water depth: 0~11000m Motor weight: aluminum alloy shell, air weight 7.9kg, sea water weight 4.4kg

Classification:

Deep Sea Motor

Deep sea thruster

Key words:

Deep Sea Motor

weight

aluminum

Main parameters

Power:

600

W

Speed:

850

rpm

Online consultation
wangnan@hrbsndj.com

Model: UWT-32
Output power: 600W
Rated voltage: 110VDC ± 5%
Rated speed: 850 r/min
Rated thrust: ≥ 32kg (forward and reverse)
Motor material: optional stainless steel, aluminum alloy, titanium alloy
Propeller material: optional aluminum alloy, titanium alloy
Control power supply: 24VDC
Control mode: analog control, CAN
Speed feedback: pulse feedback, CAN
drives: external
Compensation mode: self-compensation
Working water depth: 0~11000m
Motor weight: aluminum alloy shell, air weight 7.9kg, sea water weight 4.4kg
