Harbin Shenneng Motor Co., Ltd.

+
  • o8.jpg

Deep sea 11000 m 17kg propeller

Model: UWT-17 Output power: 400W Rated voltage: 110VDC ± 5% Rated speed: 1300 r/min Rated thrust: ≥ 17kg (forward and reverse) Motor material: optional stainless steel, aluminum alloy, titanium alloy Propeller material: optional aluminum alloy, titanium alloy Control power supply: 24VDC Control mode: analog control, CAN Speed feedback: pulse feedback, CAN drives: external Compensation mode: self-compensation Working water depth: 0~11000m Motor weight: aluminum alloy shell, 3.6kg in air and 2.3kg in sea water

Classification:

Deep Sea Motor

Deep sea thruster

Key words:

Deep Sea Motor

alloy

control

Main parameters

Power:

4000

W

Speed:

1300

rpm

Online consultation
wangnan@hrbsndj.com

Model: UWT-17
Output power: 400W
Rated voltage: 110VDC ± 5%
Rated speed: 1300 r/min
Rated thrust: ≥ 17kg (forward and reverse)
Motor material: optional stainless steel, aluminum alloy, titanium alloy
Propeller material: optional aluminum alloy, titanium alloy
Control power supply: 24VDC
Control mode: analog control, CAN
Speed feedback: pulse feedback, CAN
drives: external
Compensation mode: self-compensation
Working water depth: 0~11000m
Motor weight: aluminum alloy shell, 3.6kg in air and 2.3kg in sea water





Online consultation

If you are interested in our products, please leave your email, we will contact you as soon as possible, thank you!

Submit Message

Related Products

Pre-test motor

Pre-test motor

The company's technical research and development team has been studying brushless DC motors and permanent magnet synchronous motor systems since 1980, and has established a complete system including theoretical analysis, design, manufacturing and application of motor bodies, drivers and sensors. Professional customized solutions can be provided for deep well high temperature and high pressure motors and drive controllers, generators and power modules, motor test equipment, underwater motors and drive controllers, underwater propellers, etc.
High temperature motor

High temperature motor

HTG series high-temperature and high-pressure generators are suitable for high-temperature and high-pressure environments. They are important equipment for oilfield logging and drilling, with a maximum power of 600W.
3.5KW high temperature motor

3.5KW high temperature motor

HTG series high-temperature and high-pressure generators are suitable for high-temperature and high-pressure environments. They are important equipment for oilfield logging and drilling, with a maximum power of 600W.
22ZWX03 high temperature motor

22ZWX03 high temperature motor

HTG series high-temperature and high-pressure generators are suitable for high-temperature and high-pressure environments. They are important equipment for oilfield logging and drilling, with a maximum power of 600W.
