Deep sea 11000 m 80kg thruster

Model: UWT-80 Output power: 2600W Rated voltage: optional 110 VDC ± 10%, 310VDC ± 10% Rated speed: 1200 r/min Rated thrust: ≥ 80kg (forward and reverse) Motor material: optional stainless steel, aluminum alloy, titanium alloy Propeller material: optional aluminum alloy, titanium alloy Control power supply: 24VDC Control mode: analog control, CAN Speed feedback: pulse feedback, CAN drives: external Compensation mode: self-compensation Working water depth: 0~11000m Motor weight: titanium alloy shell, air weight 16kg, sea water weight 10kg Stainless steel shell, weight 19kg in air, weight 12kg in sea water

Classification:

Deep Sea Motor

Deep sea thruster

Key words:

Deep Sea Motor

weight

alloy

Main parameters

Power:

2600

W

Speed:

1200

rpm

Online consultation
wangnan@hrbsndj.com

Model: UWT-80
Output power: 2600W
Rated voltage: optional 110 VDC ± 10%, 310VDC ± 10%
Rated speed: 1200 r/min
Rated thrust: ≥ 80kg (forward and reverse)
Motor material: optional stainless steel, aluminum alloy, titanium alloy
Propeller material: optional aluminum alloy, titanium alloy
Control power supply: 24VDC
Control mode: analog control, CAN
Speed feedback: pulse feedback, CAN
drives: external
Compensation mode: self-compensation
Working water depth: 0~11000m
Motor weight: titanium alloy shell, air weight 16kg, sea water weight 10kg
Stainless steel shell, weight 19kg in air, weight 12kg in sea water
